Diatone Mamba TOKA 2203.5 3300KV Racing motor

MAMBA TOKA 2203.5 3300KV Racing motor

Check out all our Motors and the rest of our Diatone Products!

Specifications:

• Overall Dimension:28.929.4mm

• prop mounting shaft diameter:5mm

• Installation hole position:1616mmM3

• Prop:5inch

• Bearing9*4*4

• Shaft Diameter:4.0mm

• Lead Wire Size24AWG190mm

• slots/poles:12N14P

• Magnet Wire: 240Enameled Wire

• Stator Diamter22mm

• Stator Height:3.5mm

• Rated Voltage:4~6S (16.8V~25.2V)

• Peak Current: 15.59A

• ldle Current10V/0.3~1.0A

• Maximum Power: 380.8W

• Internal Resistance232

Package Includes:

• 1 x MAMBA TOKA 2203.5 3300KV Racing motor
